Classless Inter-Domain Routing (CIDR, pronounced "cider") is an Internet Protocol (IP) addressing methodology aimed at enhancing the efficiency of address allocation and routing on the internet. Established in 1993 by the Internet Engineering Task Force (IETF) via RFC 1519, CIDR superseded the conventional class-based IP addressing system, which was characterized by its rigidity and resulted in considerable waste of IP address space. Today, CIDR is recognized as the standard approach in contemporary IP networking.

The Problem with Classful Addressing

Before CIDR, IP addresses were divided into three primary classes: Class A, Class B, and Class C. Each class had a fixed-size block of addresses:

• Class A: Designed for large networks, provided ~16.7 million IP addresses per network.
• Class B: Meant for medium-sized networks, provided ~65,000 IP addresses per network.
• Class C: For small networks, allocated 256 IP addresses per network.

This class-based system caused two main problems:

1. Inefficient Use of IP Addresses: Many organizations received far more IP addresses than they needed, especially those assigned Class A or Class B addresses.
2. Exhaustion of Routing Table Entries: The rigid structure led to a rapid increase in the number of entries in internet routing tables, straining routers.

Benefits of CIDR

1. Efficient Address Allocation: CIDR helps conserve IP address space by enabling more precise allocations based on actual requirements.
2. Simplified Routing: It supports route aggregation, or "supernetting," which reduces the number of entries in routing tables. For example, multiple networks like 192.168.0.0/24 and 192.168.1.0/24 can be summarized into 192.168.0.0/23.
3. Scalability: CIDR's flexibility supports the growing demand for IP addresses as the internet expands.

CIDR and IPv6

CIDR was originally created to overcome the constraints of IPv4, but its concepts are equally relevant to IPv6, which naturally employs a classless addressing framework. The size of IPv6 addresses is significantly greater, consisting of 128 bits in contrast to the 32 bits of IPv4. This increased size renders CIDR even more essential for the effective management of the larger address space.

CIDR in Practice

CIDR is extensively utilized in the design of networks, encompassing allocations by internet service providers (ISPs), corporate infrastructures, and residential networks. Network administrators employ CIDR to establish subnets that effectively partition and oversee IP address space, thereby reducing waste.

For instance:

• A company requiring 1,000 IP addresses might be allocated a /22 block, which provides 1,024 addresses. In the classful system, they would have been forced to use a Class B block, wasting tens of thousands of addresses.

Conclusion

Classless Inter-Domain Routing transformed the management of IP addresses by superseding the outdated classful addressing system. By effectively conserving address space, streamlining routing processes, and accommodating the requirements of various networks, CIDR has become fundamental to contemporary networking. Its principles promote both the scalability and efficiency of the internet, establishing a robust framework for its ongoing expansion.
